The Variant M frame (plate) is designed for athletes who perform jumps from a rotation up to the axel.
Each frame size comes with a specific suspension hardness.
If the athlete's needs are different, a replacement suspension kit can be purchased separately.
Consult the guide to choose the most suitable suspension
| SUSPENSION COLOR | WHITE | GREEN | AMBER | YELLOW |
| REFERENCE WEIGHT | up to 25 kg | from 25 to 35 kg | from 35 to 50 kg | over 50 kg |
| FRAME MEASUREMENTS | 90 - 100 - 110 | 120 - 130 | 140 - 150 | 160 - 170 - 180 - 190 |
Turn the steering adjustment nut with the 17 mm nut wrench clockwise to make the steering stiffer, or counterclockwise to make it softer.
It is important to make sure that the tip is inserted with light pressure into the spherical seat. Loosen the tip lock nut with a 13 mm wrench.
Unscrew or screw the tip with a 6 mm wrench.
Check that it is inserted into the spherical seat with light pressure. Close the tip lock nut.
It is advisable to check the status of the various components every time you use the product. In particular, it is important to carefully ascertain:
ADVISE
It is preferable not to replace the suspensions close to the races (less than 1 week).
Changing the suspensions involves a change in the behavior of the tool which requires a suitable adaptation time.
For more info on how to change the suspensions, view the video tutorial.
